Beam clamp
This beam clamp is designed to make a safe connection from a beam to a for example chain hoist.
- capacity = 1 ton / 1000kg
- width = 75 - 220mm
Dimensions corresponding to the image:
- max. A = 260mm
- min. / max. B = 180 / 360mm
- C = 64mm
- D = 5mm
- E = 215mm
- min. / max. F = 102 / 155mm
- G = 25mm
- H = 22mm
This beam clamp is designed to make a safe connection from a beam to a for example chain hoist.
- capacity = 1 ton / 1000kg
- width = 75 - 220mm
Dimensions corresponding to the image:
- max. A = 260mm
- min. / max. B = 180 / 360mm
- C = 64mm
- D = 5mm
- E = 215mm
- min. / max. F = 102 / 155mm
- G = 25mm
- H = 22mm
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
| Product Dimensions: | |
|---|---|
| Product Length | 360 mm |
| Product Width | 220 mm |
| Product Height | 230 mm |
| Product Weight | 4.0 Kg |
| Package Dimensions: | |
| Package Length | 385 mm |
| Package Width | 250 mm |
| Package Height | 100 mm |
| Package Weight | 4.80 Kg |
