Air operated oil pump
This pump is suitable for dispensing grease with high pressure.
- drum application = 20 - 30kgs
- pressure ratio = 50:1
- air inlet pressure = 5 - 8 bar
- max fluid pressure = 8 bar
- air motor effective diameter = 63mm
- air consumption = 8 bar 120 L/min
- max. free flow rate = 800 g/min
- suction tube diameter = 30mm
- suction tube length = 370mm
- air inlet connection = 1/4'' quick plug 1/4'' NPT female
- oil outlet connection = 1/4''
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
| Dimensions du produit : | |
|---|---|
| Longueur du produit | 0 mm |
| Largeur du produit | 0 mm |
| Hauteur du produit | 0 mm |
| Poids du produit | 0,0 Kg |
| Dimensions de l'emballage : | |
| Longueur du paquet | 0 mm |
| Largeur du paquet | 0 mm |
| Hauteur du paquet | 0 mm |
| Poids du Colis | 5,00 Kg |
