Circuit board

Suitable for MIG-MAG welding machines MG150 and MG200.

Plasma cutter / plasma cutting machine

This Soldatech powered by HG plasma cutter cuts steel and aluminum with high-quality results. The PL100HG is among the heavier plasma cutters, it ignites very easily thanks to the HF ignition and cuts easily through rusted, coated or structured material up to 35mm. The plasma cutter has four swivel castors, making it mobile during use.

The PL100HG has a user-friendly control panel and can even be adjusted during cutting work to achieve the best cutting result.

The modern IGBT inverter technology ensures that the PL100HG delivers sustainable performance with more power and a higher duty cycle. Overload protection in combination with a built-in fan prevents overheating and ensures that high-quality cutting performance is guaranteed over a long period of time.

Ideal for cutting carbon steel, low alloy steel, stainless steel and aluminum alloys.

Each PL100HG comes standard with:

• Soldatech PL141M3 plasma torch with 5m cable

• Work clamp with 3m 16mm² cable

• Gas line of 4m with quick coupling

• 5-pin 32A plug with 3m 4x2.5mm² cable

• Standard 9mm Dinse cable couplings

Technical specifications:

• voltage = 400V - 3 phase

• frequency = 50/60Hz

• circuit breaker = 3x 20A B-char

• duty cycle (at 20°C ambient temperature) = 60% - 100A

• duty cycle (at 40°C ambient temperature) = 60% - 100A


• welding current range = 20 - 100A

• max. unloaded voltage = 325V

• max. cutting thickness = 35mm

• average air / gas consumption = 220L/min

• protection class = IP21S

• dimensions = 719 x 308 x 633mm

• weight = 43kg

Plasma torch PL141 / plasma cutting torch / cutting torch

This Soldatech cutting torch has an ergonomic handle and a ball joint at the bottom of the torch. This, in combination with the optimal position of the switch, ensures great ease of use in all cutting positions.

All consumables for this torch are also available.

• connection = euro connector

• length = 6 meters

• duty cycle = 60%

• current = 140A

• air pressure = 4.5 - 5.0 bar

• air / gas flow = 220L/min

Includes:

• 2-point spacer = 1x PL141A
• ceramic head= 1x PL141C
• TIP 1.7mm = 1x PL141
• gas distributor = 1x PL141D
• LT141 insulation ring = 1x PL141R
• electrode = 1x PL141E
• LT141 gas pin = 1x PL141P
• LT141 rubber ring = 1x PL141RR


Plasma cutter / plasma cutting machine

This Soldatech powered by HG plasma cutter cuts various materials with high-quality results. The PL50HG is a compact, powerful and easy to operate plasma cutter equipped with Pilot ARC pre-ignition. This in combination with the HF ignition makes this cutter very easy to ignite and it is capable of cutting through rusted, coated or structured material up to 20mm without any difficulty.

The PL50HG has a user-friendly control panel and can even be adjusted during cutting work to achieve the best cutting result.

The modern IGBT inverter technology not only ensures that the PL50HG delivers long-lasting performance with more power, but it also makes the welder lightweight and portable. Overload protection in combination with a built-in fan prevents overheating and ensures that high-quality welding performance is guaranteed for a long time.

Ideal for cutting low alloy steel, stainless steel and aluminum alloys.

Each PL50HG comes standard with:

• Soldatech PL80M5 plasma torch with 5m cable

• Welding ground clamp with 2m 16mm² cable

• Gas line of 4m with hose clamps

• Neoprene power cable 2m 3x2.5mm²

• European dinse couplers 9mm

Technical specifications:

• voltage = 230V - 1 phase

• frequency = 50/60Hz

• circuit breaker = 20A C-kar

• input power = 7.6kVA

• duty cycle (at 20°C ambient temperature) = 60% - 50A

• duty cycle (at 40°C ambient temperature) = 20% - 50A


• welding current range = 15 - 50A

• max. unloaded voltage = 293V

• max. cutting thickness = 20mm

• air consumption = 220L/min

• protection class = IP21S

• dimensions = 459 x 200 x 338mm

• weight = 11kg

Plasma cutter / plasma cutting machine
This Soldatech powered by HG plasma cutter cuts various materials with high-quality results. The PL70HG is a compact, powerful and easy to use plasma cutter that is equipped with Pilot ARC ignition. This in combination with the HF ignition makes this cutter very easy to ignite and it is capable of cutting smoothly through rusted, coated or structured material up to 25mm.
The PL70HG has a user-friendly control panel and can even be adjusted during cutting work to achieve the best cutting result.

The modern IGBT inverter technology not only ensures that the PL70HG delivers long-lasting performance with more power, but it also makes the welder lightweight and portable. Overload protection in combination with a built-in fan prevents overheating and ensures that high-quality welding performance is guaranteed for a long time.

Ideal for cutting low alloy steel, stainless steel and aluminum alloys.

Each PL70HG comes standard with:

• Soldatech PL80M5 plasma torch with 5m cable

• Workpiece clamp with 2m 16mm² cable

• Gas pipe of 4m with hose clamps

• 5-pin 32A plug with 2.5m 4x2.5mm² cable

• Standard 9mm Dinse cable couplings

Technical specifications:

• voltage = 400V

• frequency = 50/60Hz

• fuse protection = 3x 16A C-kar

• input power = 9.4kVA

• duty cycle = 60% - 70A / 100% - 54A (at 40 degrees ambient temperature)

• welding current range = 25 - 70A

• max. unloaded voltage = 330V

• recommended cutting thickness = 17mm

• max. cutting thickness = 25mm

• average air / gas consumption = 220L/min

• protection class = IP21S

• dimensions = 550 x 245 x 405mm

• weight = 22.7kg

Plasma torch PL80 / plasma cutting torch / cutting torch

This Soldatech cutting torch has an ergonomic handle and a ball joint at the bottom of the torch. This, in combination with the optimal position of the switch, ensures great ease of use in all cutting positions.

All consumables for this torch are also available.

• connection = euro connector

• length = 5 meters

• duty cycle = 60%

• current = 80A

• air pressure = 4.5 - 5.0 bar

• air / gas flow = 220L/min

Comes standard with

• ceramic cap = 1x CUT80WTC

• TIP = 2x 1.1mm
• electrode = 2x CUT80WTTH
• disassembly key


Plasma cutter

This Soldatech Original plasma cutter cuts with high-quality results through almost all ferrous and non-ferrous materials. The cutter ignites very easily thanks to the HF ignition and cuts smoothly through rusted, coated or textured material up to 12mm.
The PL40E has a user-friendly control panel and can even be adjusted during cutting work, so that the best cutting result is achieved.
The modern IGBT inverter technology not only ensures that the PL40E delivers long-lasting performance with more power, but it also makes the cutter lightweight and portable. Overload protection in combination with a built-in fan prevents overheating and ensures that high-quality cutting performance is guaranteed for a long time.
Ideal for cutting low alloy steel, stainless steel and aluminum alloys.

Each PL40E comes standard including:

• Torch with 2.5m cable

• Workpiece clamp with 1.8m cable

• Compressed air / shielding gas hose of 2m

• 3x cutting tip

• 3x cutting electrode

• 3x ceramic cap

Optimal cutting thickness (when using compressed air):

• copper = 1 - 4mm

• stainless steel = 1 - 8mm

• aluminum = 1 - 8mm

• steel = 1 - 10mm

Technical specifications:

• voltage = 230V

• frequency = 50 / 60Hz

• input power = 5.8kW

• duty cycle (at 20°C ambient temperature) = 45% - 40A
• duty cycle (at 40°C ambient temperature) = 20% - 40A

• ampere range = 15 - 40A

• continuously adjustable cutting current = 15 - 40A

• protection class = IP21S

• insulation class = H

• dimensions = 410 x 140 x 287mm
• weight = 6.4kg

Rubber ring plasma torch

Suitable for the plasma torch PL141.

• price per piece

Rubber ring plasma torch

Suitable for the plasma torch PL141.

• 10 pieces

Plasma cutter wear parts set

This set of consumables are suitable for the CUT40WT plasma torch. The set consists of the following parts:

• 2 electrodes

• 4 cutting tips

• 2 ceramic heads

• 2 ceramic rings

Collet

Convient aux torches de soudage TIG.

• Electrodes de diamètre = 1,6mm

• longueur = 50mm

Collet

Convient aux torches de soudage TIG.

• Electrodes de diamètre = 2,0mm

• longueur = 50mm

Collet

Convient aux torches de soudage TIG.

• Electrodes de diamètre = 2,4mm

• longueur = 50mm

Pince

Convient aux torches de soudage TIG.

• Electrodes de diamètre = 3,2mm

• longueur = 47mm

Collet

Convient aux torches de soudage TIG.

• Electrodes de diamètre = 3,2mm

• longueur = 50mm

Spot weld nozzle

Suitable for the MIG MAG torch MLT25.

• diameter = 22mm

• bore size = 15mm

• length = 68mm

Spot weld nozzle

Suitable for the MIG MAG torch MLT25.

• diameter = 22mm

• bore size = 15mm

• length = 68mm

• 10 pieces

Spring
Suitable for the MIG MAG torch MLT15.

• length = 12mm

Spring
Suitable for the MIG MAG torch MLT25.

• length = 16mm
